Description
- Degree of protection: IP 66
- Round type light distribution
- Available with emergency version
- Available with microwave smart module
- Multiple mounting options such as pole mount and wall mount
| Certification | |||
|
International approvals
|
CCC, CNEX | ||
|
Coding
|
Ex d e mb II C T6/T5 Gb, Ex tD A21 IP66 T80ºС/ T95ºС |
||
|
Conformity to standards
|
IEC 60079 / IEC 60598 | ||
| Material | |||
|
Body material
|
Aluminum alloy with epoxy powder coating | ||
|
Diffuser
|
Polycarbonate | ||
| Light source | |||
|
Wattage Type
|
30 W, 50 W LED | ||
|
Luminous flux
|
140 lm / W | ||
|
Life
|
50000 h | ||
|
Rated voltage
|
220 V – 240 V AC 50 Hz / 60 Hz | ||
|
Class of insulation
|
Class I | ||
|
Degree of protection
|
IP 66 | ||
|
Operating temperature
|
-20 ºC to +40 ºC | ||
|
Cable entry
|
G3/4 | ||
|
Corrosion-proof class
|
WF2 | ||
| Emergency | |||
| Battery voltage | 7.4 V DC | ||
| Battery capacity | 2.5 Ah | ||
| Emergency power | 5 W | ||
| Duration | >150 min | ||
| Model | Lamp power | Lamp type | Operating current | Color temperature | Weight |
| (W) | (W) | (A) | (K) | (kg) | |
| BPC8767/30/LED | 30 | LED | 0.75 | 5700 (cool white) | 3.0 |
| BPC8767/50/LED | 50 | LED | 1.25 | 5700 (cool white) | 3.0 |
| BPE8767/30/LED | 50 | LED | 1.25 | 5700 (cool white) | 3.5 |
