Description
● Suitable for Zone 1 and Zone 2 applications
● Providing reliable operations
● Robust enclosure providing superior impact resistance
● Available for use as streetlight and floodlight
● Degree of protection: IP 66; class of corrosion resistance: WF2
| Certification | |||
|
International approvals
|
CCC, CNEX | ||
|
Coding
|
Ex d e mb IIC T6 Gb, Ex tD A21 IP66 T80ºС |
||
|
Conformity to standards
|
IEC 60079 / IEC 60598 | ||
| Material | |||
|
Body material
|
Aluminum alloy with epoxy powder coating | ||
|
Diffuser
|
Polycarbonate | ||
| Light source | |||
|
Wattage Type
|
100 W, 150 W LED | ||
|
Luminous flux
|
140 lm / W | ||
|
Life
|
50000 h | ||
|
Rated voltage
|
100 V – 277 V AC 50 Hz / 60 Hz | ||
|
Class of insulation
|
Class I | ||
|
Degree of protection
|
IP 66 | ||
|
Operating temperature
|
-20 ºC to +40 ºC | ||
|
Cable entry
|
G3/4 | ||
|
Corrosion-proof class
|
WF2 | ||
| Model | Lamp power | Lamp type | Operating current | Color temperature | Weight |
| (W) | (W) | (A) | (K) | (kg) | |
| BLC8616/100/LED | 100 | LED | 1.8 | 5700 (cool white) | ≤10 |
| BLC8616/150/LED | 150 | LED | 3.2 | 5700 (cool white) | ≤10 |
